• 2 x NO contacts for each pedal
• With safety trigger mechanism - i.e. the boot must be inserted into the housing to activate the trigger before the pedal can be depressed

All of our footswitches feature:

• Easy wiring and installation
• Rugged double-insulated enclosures in self-extinguishing thermoplastic
• M20 cable entry
• Sealed to IP54
• Standard click-on contact blocks - up to 3 contacts
• Contacts with 16A (thermal) rating, 690V insulation voltage
• NO contacts are slow-break, double-gap, self-cleaning
• NC contacts are positive-break (EN418)
• AC15 contact ratings (e.g AC solenoids): 16A@24Vac 5A@230Vac, 4A@400Vac
• DC13 contact ratings (e.g. DC solenoids): 4A@24Vdc
• Suitable fuse rating gG-10A/500V
